    M19 Self-locking Rear-mounted Waterproof Connector
    M19 Self-locking Rear-mounted Waterproof Connector
    М19 Self-locking Right Angle Waterproof Connector
    М19 Self-locking Right Angle Waterproof Connector
    М19 Waterproof Threaded Connector
    М19 Waterproof Threaded Connector
    M19 Self-locking Waterproof Connector
    M19 Self-locking Waterproof Connector
    M19 Thread Right Angle Waterproof Connector
    M19 Thread Right Angle Waterproof Connector

    Features

    🌊  Waterproof Excellence : IP67-IP68 rated – Dust-tight and waterproof.

    🔧  Flexible Installation : Self locking,Screw locking,Panel Mount,Butt Joint,Field Assembly.

    ❄️ Wide Temperature Range : Operates reliably from -40°C to +105°C, perfect for harsh environments.

    💪  Exceptional Durability : Withstands over 500 mating cycles, ensuring long-term reliability.

    Get a Quotation

    Inquiry Form for Bulk Order?

    Please fill in your details and requirements below, and our team will get in touch with you as soon as possible.




      Applications:

      • Outdoor Displays and Billboards: Reliable, weather-resistant power for LED signage.
      • AV/Entertainment Systems: Durable,waterproof electrical connectors for outdoor stages.
      • Outdoor Lighting and PV Solar: Stable power for LED lights and solar panels.
      • Marine Solutions: Corrosion-resistant, waterproof links for boats and docks.
      • Wireless and Industrial Use:Network Devices (AP, Antennas, Base Stations),Factory equipment.
      •
      ImageSKUNameConnector typeNumber of positionsOrientationRated voltageRated currntCompatible wire rangeProtection gradeInstallation typeContact diameterWire gaugeTemperature range
      No Image 29-1331093-01-C M19 Waterproof Circular Connector 3+9 Pin Male Plug 125V/30V 15A/2A Thread Over Molding Plug 3+9 Pin Straight 125V/30V 15A/2A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0/φ0.8 MAX φ13 ﹣40℃﹣105℃
      No Image 29-1331093-01 M19 Waterproof Circular Connector 3+9 Pin Female Plug 125V/30V 15A/2A Thread Assembly Plug 3+9 Pin Straight 125V/30V 15A/2A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0/φ0.8 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1331004-01-C M19 Waterproof Circular Connector 4 Pin Male Plug 300V 15A Thread Over Molding Plug 4 Pin Straight 300V 15A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0 MAX φ13 ﹣40℃﹣105℃
      No Image 29-1331004-01 M19 Waterproof Circular Connector 4 Pin Female Plug 300V 15A Thread Assembly Plug 4 Pin Straight 300V 15A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1311093-01 M19 Waterproof Circular Connector 3+9 Pin Female Plug 125V/30V 15A/2A Thread Assembly Connector Plug 3+9 Pin Straight 125V/30V 15A/2A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0/φ0.8 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1311009-01 M19 Waterproof Circular Connector 9 Pin Female Plug 60V 5A Thread Assembly Plug 9 Pin Straight 60V 5A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ1 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1311008-01-C M19 Waterproof Circular Connector 8 Pin Female Plug 60V 5A Thread Over Molding Plug 8 Pin Straight 60V 5A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ1 MAX φ13 ﹣40℃﹣105℃
      No Image 29-1311008-01 M19 Waterproof Circular Connector 8 Pin Female Plug 60V 5A Thread Assembly Plug 8 Pin Straight 60V 5A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ1 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1311004-01-C M19 Waterproof Circular Connector 4 Pin Female Plug 300V 15A Thread Over Molding Connector Plug 4 Pin Straight 300V 15A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0 MAX φ13 ﹣40℃﹣105℃
      No Image 29-1311004-01 M19 Waterproof Circular Connector 4 Pin Female Plug 300V 15A Thread Assembly Connector Plug 4 Pin Straight 300V 15A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1151008-01 M19 Waterproof Circular Connector 8 Pin Male Socket 60V 5A Thread Socket Socket 8 Pin Straight 60V 5A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ1 MAX φ13 ﹣40℃﹣105℃
      No Image 29-1151004-01 M19 Waterproof Circular Connector 4 Pin Male Socket 300V 15A Thread Socket Socket 4 Pin Straight 300V 15A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0 MAX φ13 ﹣40℃﹣105℃
      No Image 29-1131009-01 M19 Waterproof Circular Connector 9 Pin Male Plug 60V 5A Thread Assembly Plug 9 Pin Straight 60V 5A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ1 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1131008-01-C M19 Waterproof Circular Connector 8 Pin Male Plug 60V 5A Thread Over Molding Plug 8 Pin Straight 60V 5A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ1 MAX φ13 ﹣40℃﹣105℃
      No Image 29-1131008-01 M19 Waterproof Circular Connector 8 Pin Male Plug 60V 5A Thread Assembly Plug 8 Pin Straight 60V 5A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ1 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1131004-01-C M19 Waterproof Circular Connector 4 Pin Male Plug 300V 15A Thread Over Molding Connector Plug 4 Pin Straight 300V 15A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0 MAX φ13 ﹣40℃﹣105℃
      No Image 29-1131004-01 M19 Waterproof Circular Connector 4 Pin Male Plug 300V 15A Thread Assembly Connector Plug 4 Pin Straight 300V 15A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1111004-01-C M19 Waterproof Circular Connector 4 Pin Female Plug 300V 15A Thread Over Molding Plug 4 Pin Straight 300V 15A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0 MAX φ13 ﹣40℃﹣105℃
      No Image 29-1111004-01 M19 Waterproof Circular Connector 4 Pin Male Plug 300V 15A Thread Assembly Plug 4 Pin Straight 300V 15A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.0 MAX φ10.6 ﹣40℃﹣105℃
      No Image 29-1111003-01 M19 Waterproof Circular Connector 3 Pin Male Plug 600V 20A Thread Assembly Plug 3 Pin Straight 600V 20A 0.3mm2-2.5mm2/24AWG-12AWG IP68 Screw locking φ2.4 MAX φ10.6 ﹣40℃﹣105℃
