2 Pin 630A Rear Mount MSD Connector Manual Service Disconnect Socket IP67
- Easy Plug
- Excellent Electrical Insulation
- Secondary Buckle
- Strong Waterproof Performance
- Way To Install: Front Install / Back Install
Inquiry Form for Bulk Order?
Please fill in your details and requirements below, and our team will get in touch with you as soon as possible.
Description
The MSD Connector is a specialized safety device with high-voltage interlock function designed for the high-voltage boxes or battery boxes of electric vehicles. Primarily used to protect against excessive current and allow quick disconnection of high-voltage circuits, it’s an essential tool for technicians working on or repairing electric vehicles.
Key Features
- Two-stage lever with HVIL time delay: Ensures safe and reliable power disconnection, minimizing the risk of electrical shock during maintenance or repair work.
- Integrated internal HVIL: Provides additional protection and peace of mind, preventing accidental contacts and reducing the potential for electrical hazards.
- Unique cooling structure: Our MSD Connector features an innovative cooling design that effectively dissipates heat, ensuring optimal performance and prolonging the lifespan of electrical components.
- Dual-channel design with lower temperature rise: Optimized electrical pathways and enhanced heat dissipation result in significantly lower temperature rise, reducing the risk of overheating and ensuring reliable operation.
- Easy and tool-free unmatting: No need for specialized tools or equipment to disconnect the MSD Connector, saving time and effort during service or maintenance tasks.
MSD Connector Drawing
Application
Chevy
Motor drive unit of an elect
HQ720
Electric car
MSD07
EV batteries
Locking Method | Secondary Buckle |
||
---|---|---|---|
Color | Orange |
||
Electrical Protection | IP2XB |
||
Contact Termination | Crimp |
||
Mounting Feature | Flange Mount |
||
Application | Automotive Electronics |
||
Locking Method | Secondary Buckle |
Color | Orange |
Electrical Protection | IP2XB |
Contact Termination | Crimp |
Mounting Feature | Flange Mount |
Application | Automotive Electronics |
Environmental
Flammability | UL94V-0 |
||
---|---|---|---|
Ingress Protection | IP67 |
||
Operating Temperature | -40℃~125℃ |
||
Flammability | UL94V-0 |
Ingress Protection | IP67 |
Operating Temperature | -40℃~125℃ |
Specifications
Shielding | Shield |
||
---|---|---|---|
Contact Material | Copper Alloy |
||
Contact Finish | Silver Plating |
||
Mounting Type | Panel Mount |
||
Shell Material | Nylon |
||
Connector Type | Socket |
||
Shielding | Shield |
Contact Material | Copper Alloy |
Contact Finish | Silver Plating |
Mounting Type | Panel Mount |
Shell Material | Nylon |
Connector Type | Socket |
Electrical
Rated Current | 400A-630A |
||
---|---|---|---|
Rated Voltage | 800V |
||
Rated Current | 400A-630A |
Rated Voltage | 800V |
Weight | 62 g |
---|---|
Locking Method | Secondary Buckle |
Flammability | UL94V-0 |
Color | Orange |
Shielding | Shield |
Contact Material | Copper Alloy |
Contact Finish | Silver Plating |
Electrical Protection | IP2XB |
Mounting Type | Panel Mount |
Contact Termination | Crimp |
Shell Material | Nylon |
Connector Type | Socket |
Mounting Feature | Flange Mount |
Rated Current | 400A-630A |
Rated Voltage | 800V |
Ingress Protection | IP67 |
Operating Temperature | -40℃~125℃ |
Application | Automotive Electronics |
Q: How does the unique cooling structure of the MSD Connector benefit me?
A: The MSD Connector is designed with a unique cooling structure that ensures lower temperature rise during operation. This prevents overheating and increases the overall efficiency and performance of the device.
Q: Can you explain the dual-channel design of the MSD Connector?
A: The MSD Connector incorporates a dual-channel design, which enhances its reliability and safety. This design allows for better signal transmission and reduces the risk of electrical interference.
Q: Is it easy to disconnect the MSD Connector?
A: Yes, disconnecting the MSD Connector is extremely easy as it does not require any tools. This makes it convenient and hassle-free to unmate the connector whenever needed.
Q: Can the receptacle of the MSD Connector be placed in different positions?
